HA-1000ACEIII
SS期兼用1トン運搬車
- 1トンの運搬最大積載量
- 最高の走行エンジン搭載
- コンパクトなデザインと低重心型設計
かんがみエスエスは、さまざまな環境や目的に合った製品を
検証された品質と最新の技術、優れたデザインで提供しています。
かんがみエスエスは、さまざまな環境や目的に合った製品を
検証された品質と最新の技術、優れたデザインで提供しています。
HA-1000ACEIII
米国コーラ20馬力走行エンジン
重量物の搭載を考慮した大容量の油圧ポンプとシリンダーは1トンをやすやすと積載
国内初の1トンの大容量運搬車
大容量の油圧機能
密植獣姦、ドクミト作業など限られたスペースでの機動性発揮
かさばる重量物や大量の果物容器搭載可能
各種インストルメントパネルと広い運転領域
| MODEL : HA-1000ACEIII | |||||
|---|---|---|---|---|---|
| Length*Width*Height | mm | 3440*1380*1220 | |||
| Weight | kg | 985 | |||
| Main Part | Driving Format | Wheel | |||
| Shift gear type | 5 forward, 1 reverse, 2 sub-speed | ||||
| Steering | Handle | ||||
| Driving Clutch Format | Disc friction type (dry single plate) | ||||
| Brake | Stop brake: disc type (hydraulic), parking brake: disc type (combined with stop brake) | ||||
| Speed | km/h | Max: 14.9, Min: 1.54 | |||
| Driving engine part | Type of lubricant | GL-4 or higher (#90) | |||
| Tank Capacity | L | 1.8 | |||
| Format | KOHLER CH640(USA) | ||||
| Max. Output | kw(ps) | 15 | 16.8 | ||
| Continuous rated rotational speed | rpm | 3000 | 3100 | ||
| Format and standard | 2-cylinder 4-cycle air-cooled | ||||
| Fuel type | Unleaded gasoline | ||||
| Tank Capacity | L | 22 | |||
| Type of lubricant | SAE 10W-30, API SH, SJ or higher | ||||
| Hydraulic system | Tank Capacity | L | 1.5 | ||
| Max Torque | Nm | 44.06 | |||
| Hydraulic cylinder type | Double acting hydraulic cylinder | ||||
| Hydraulic pump type | Gear type | ||||
| Discharge pressure | kg.f/cm3 | 140 | |||
| Type of hydraulic oil | ISO VG 46# | ||||
| Tank Capacity | L | 13 | |||
| Carrying capacity | kg | 1000 | |||
| Loading box size | mm | 2115*1115*270 | |||
